3 Axis Servo Motor for Machine 80-1800T
Product Description:
Rugged construction with 3 Servo Motors and Telescopic Single or Double Arm.
Reliable and stable design meets the requirements for high precision products and continuous running production.
Easy to adapt to multiple configurations and different product requirements.
Highly reliable to endure continuous long shifts production cycles.
User friendly with intuitive interface designed for easy operation.
Safety minded design.
Type: Large Capacity 3 Axis Servo Robot
Application: Recommended for detailed and sophisticated products
Standard fixture functions: 2 suckers & 2 holders
General Technical Information
Durable Arm Belt Structure:
The servo motor and dual belts are installed side by side to optimize and balance force, this design increases the life spam by 30%
Negative pressure gauge adjustments:
Convenient and user friendly negative gauge down-tilted design facilitates easy adjustments and pressure monitoring.
Proximity switches hidden design:
The proximity switch for horizontal moving are hidden to avoid operating errors and damage to the robot.
Start switch:
Easy to move start switch can be positioned for convenience.
Power: 220VAC 50/60Hz
Working Air Pressure: 4-7 kgf/cm2
Drive System: Servo Motor
Type: Telescopic
Gripper Rotation: Fixed 90°
Max Load (w/ tool): 10kg.
