BJM Series – Double Color Injection Molding Machines
Energy-Saving Optimizes Production Cost, Easy to Operate and Excellent performance
Clamping force 1,600 - 4,000Kn
Contact us at: sales@kontrolpi.com // +1.619.606.2487
·Machine is equipped with a rotary mold platen specifically designed for the production of double color products.
·The rotary table was designed with a very accurate and stable mechanism.
·External mold hydraulic and water-cooling systems for easy for operation and maintenance.
·Energy-Savings hydraulic servo system with high precision control.
·Flexibility with optional rotary tables and shafts that can produce many kinds of product.
·Variable ways for ejection control.
·Two independent controls for the shot platforms, injection simultaneously is achieved to shorten the molding time.
Working Principle
The injection molding machine injects the first material into the mold and the plastic takes the shape. After the mold is open, the movable rotary mold platen turns around with the other work pieces by 180º then the machine makes the second injection after the injection nozzles is directed at the cavities of the mold and the mold is closed, and then finally takes shape; Or the first material injection and the second material can be done at the same time to take shape.
BJM Series - Comun Applications
BJM series multi-material injection molding machines are widely used in many multi-color products including the infant child products industry. For example, double color dust covers, milk bottles and sport water bottles, double color tooth brushes, handles, bowls, spoons and multi-colored toys, etc.
